Carriages and Carriage Parts - Rated by the fork carriage lifting capability, there are four sizings of hook type blade carriages. The hook type blade carriages have been standardized.
The carriage bar spacing for Class 1 is around 13 inches and the Class 1 carriage is rated to carry cargo up to 2000lbs. The Class 2 carriage is rated to carry loads up to 5,500lbs with carriage bar spacing of sixteen inches. Class III carriages are rated for cargo up to 10,000 lbs. The carriage bar spacing for this class is 20 inches. Class IV carriages are rated for cargo up to 15,500 lbs. The carriage bar spacing used for this capacity is twenty five inches.
The carriages for pin type forks may be different depending on the maker. Pin mounted tines can vary by the amount of offset between the blade eye and the blade. Carriage capacity would be determined by the carriage pin size and by the fork size.
