Fork Extension for Forklifts
Forklift Fork Extensions - Lift Truck extensions are a terrific alternative whenever there is a need to reach further than your current forks would allow. In certain situations whenever you have a load which exceeds more than can be safely lifted on your forklift, an extension can help you carry out your task safely.
Increasing Lift Truck Productivity
Lift truck extensions offer the added support and capacity required when picking up long pallets, containers or very heavy loads. Moreover, the extensions add more length to the blades that helps the operator to be able to reach increased distances. Making use of lift truck extensions truly saves a business the need to purchase separate machinery in order to complete the task. This could save possibly thousands of dollars while adding more efficiency and productivity choices using the machine you already have.
Many extensions just slip over the typical forklift blades. Extensions could be acquired in order to fit forks that have widths of 4", 5" and 6". It is essential to measure your extensions so as to obtain a right fit. Knowing that extensions have an inner width which is half an inch wider compared to the the size stated is paramount to ensuring the accurate fit. When obtaining your extension size, make certain it is equivalent to your blade's width. For example, if you have forks that are 6 inches wide, you will make use of an extension which is six inches wide.
OSHA Standards
There is safety standards established by OSHA that regulate the length of extension which you could utilize. Based on the regulation, extensions can not be longer than 50% of the actual blade length. Abiding by those rules will help to maintain a safe operation. A yellow powder coat finish is added to the steel forklift extensions in order to prevent rust. The two most popular sizes for forklift extensions in the business are 60" and 72", even though, various lengths are obtainable.
Securing Mechanism
There are two individual securing mechanisms existing. The first option secures the extensions onto the lift truck with one pull pin. The next and safer choice is the safety loop which is welded on and provides a more stable attachment of the extension. The lift truck extensions are offered in both non-tapered or tapered for most container and pallet loads. Triangular extensions are used whenever moving cylinder loads.
Cylinder Loads
Loads which consist of drums, coils or pipes are considered to be cylinder loads. Extensions for cylinder loads are also constructed of steel. They are built to fit forks up to 2" thick and that are 4" to 5" in width. Fixed in place utilizing a locking bar, they slip on and off effortlessly. Triangular extensions vary in length from 54" to 60".
Safety Measures
Safety measures should be utilized whenever using whichever industrial tool or machine and lift truck extensions are no different. Inspecting your lift truck extensions prior to using them is a very great habit to get into. After placing an extension onto the forklift, the attaching mechanism should be double checked. Physical injury or destruction to the load can take place if the extensions were to become loose and fall off. Following OSHA regulations would also help to be able to guarantee the safety of the one operating it and individuals working close by.
