Drive Axle for Forklifts

Forklift Drive Axle - A lift truck drive axle is a piece of equipment that is elastically fastened to a vehicle frame using a lift mast. The lift mast is fixed to the drive axle and can be inclined round the axial centerline of the drive axle. This is done by at the very least one tilting cylinder. Forward bearing elements combined with rear bearing parts of a torque bearing system are responsible for fastening the drive axle to the vehicle frame. The drive axle could be pivoted round a swiveling axis oriented horizontally and transversely in the vicinity of the back bearing components. The lift mast is likewise capable of being inclined relative to the drive axle. The tilting cylinder is connected to the vehicle framework and the lift mast in an articulated fashion. This enables the tilting cylinder to be oriented nearly parallel to a plane extending from the swiveling axis to the axial centerline.

Lift truck units like H40, H45 and H35 which are produced in Aschaffenburg, Germany by Linde AG, have the lift mast tilt ably affixed\connected on the vehicle frame. The drive axle is elastically connected to the lift truck frame by numerous bearing devices. The drive axle has tubular axle body along with extension arms attached to it and extend rearwards. This type of drive axle is elastically attached to the vehicle frame utilizing back bearing parts on the extension arms along with forward bearing devices located on the axle body. There are two rear and two front bearing tools. Each one is separated in the transverse direction of the lift truck from the other bearing tool in its respective pair.

The drive and braking torques of the drive axle are sustained through the rear bearing elements on the framework by the extension arms. The load and the lift mast produce the forces which are transmitted into the street or floor by the framework of the vehicle through the drive axle's front bearing elements. It is essential to be certain the components of the drive axle are configured in a firm enough way in order to maintain strength of the lift truck truck. The bearing elements could reduce slight bumps or road surface irregularities throughout travel to a limited extent and give a bit smoother operation.
